Engine features:

• Engine is Environmental Protection Agency (EPA) Tier II compliant
• One-side serviceability of fuel system, lubrication system, seawater pump, and air cleaner
• PTO options: 12- or 24-volt electric clutch

Generator features:

• 90°C/50°F prime power rated
• Superior Kohler Fast-Response(TM) PMG generator ends
• Class H insulation
• 12-lead reconnectable alternator
• The generator complies with NEMA, IEEE, and ANSI standards for temperature rise.
• The alternator uses a permanent-magnet, Fast-Response(TM) excitation system.
• The alternator has a two-thirds pitch stator and skewed rotor.
• The generator has a solid-state, volts-per-hertz voltage regulator.
• The brushless, synchronous generator is broadrange and reconnectable.
• The windings are vacuum-impregnated with fungus-resistant epoxy varnish.
• The generator sustains short-circuit current up to 300% of the rated current for up to 10 seconds.
•

Generator Controls

Decision-Maker(R) 6000
Decision-Maker(R) 3000
Decision-Maker(R) 550
Decision-Maker(R) 1
Decision-Maker(R) 3+

Accessories

• Line circuit breakers
• Sound shield
• Siphon break
• Remote connection/extension harness
• Oil level indicator
• Low coolant level indicator

 Spec. Sheet - g2105.pdf 536 Kb

Dim. Drawing - adv7141.pdf 634 Kb
