Engine features:

• Integral heat exchanger
• CARB/EPA emission compliant (Low CO)
• One-side serviceability of fuel filter, cooling systems, and lubrication system
• Sequential-port throttle-body fuel injected
• Attached overflow bottle

Generator features:

• Remote start 12-pin connector
• Voltage regulation of ±1.5%
• Rotor and stator are vacuum impregnated and coated with high-bond epoxy varnish. Varnish helps prevent corrosion in high-humidity areas.
• Copper windings ensure minimal heat buildup. Insulation meets NEMA standards for class H insulation.
• Directly connected to the engine, the generator has sealed precision ball bearings with a precision-machined steel sleeve in the end bracket (or end bearing tolerance ring) to prevent shaft misalignment and extend bearing life.
•

 Hertz:50 Hz

Generator with sound shieldWidth:500 mm (19.69 in.)Height:467 mm (18.39 in.)Length:773 kg (30.43 in.)Weight, wet:132 kg (290 lbs)

Generator without sound shieldWidth:466 mm (18.35 in.)Height:445 mm (17.51 in.)Length:691 kg (27.2 in.)Weight, dry:118 kg (260 lbs)Weight, wet:120 kg (265 lbs)

Accessories

• Sound Shield
• Ship-to-Shore Switch
• Remote Digital Gauge
• Oil Pressure and Water Temperature Sender
• Remote Start Panel
• Remote Connection/Extension Harness
• 12-Inch Remote Wiring Harness
• Line Circuit Breakers
• Sea Spares(TM) Maintenance Kit
